LIANG Qi-fan, CUI Ji-wei, ZHANG Xin-ru, GUO Yu-miao, WANG Ruo-ning, DI Liu-qing. Preparation and in vitro Evalution of Glycyrrhizic Acid Self-Assembled Micelles Loading Tanshinone ⅡA[J]. Journal of Nanjing University of traditional Chinese Medicine, 2022, 38(6): 534-540. DOI: 10.14148/j.issn.1672-0482.2022.0534
Citation: LIANG Qi-fan, CUI Ji-wei, ZHANG Xin-ru, GUO Yu-miao, WANG Ruo-ning, DI Liu-qing. Preparation and in vitro Evalution of Glycyrrhizic Acid Self-Assembled Micelles Loading Tanshinone ⅡA[J]. Journal of Nanjing University of traditional Chinese Medicine, 2022, 38(6): 534-540. DOI: 10.14148/j.issn.1672-0482.2022.0534

Preparation and in vitro Evalution of Glycyrrhizic Acid Self-Assembled Micelles Loading Tanshinone ⅡA

More Information
  • Received Date: March 04, 2022
  • Available Online: June 06, 2022
  •   OBJECTIVE  Encapsulate tanshinone ⅡA (Tan ⅡA) in glycyrrhizic acid (GL) self-assembled micelles, to investigate the preparation process and characterization, and evaluate the anti-glioma cell activity in vitro.
      METHODS  Thin film dispersion method was used to prepare self-assembled micelles loaded with tanshinone ⅡA glycyrrhizic acid (TGM, Tan ⅡA-GL/Micelle). The particle size, polydispersity index (PDI) and Zeta potential of TGM were measured. The typical morphological characteristics of TGM were observed by transmission electron microscopy (TEM). HPLC was employed to determine the encapsulation rate of TGM, then the drug release of TGM under different pH conditions was investigated by dialysis bag method. The in vitro blood-brain barrier (BBB)-crossing ability of TGM was inspected by inverted fluorescence microscopy. Quantitative cell uptake experiment to investigate the specific mechanism of cell uptake. The cytotoxicity of free Tan ⅡA, GL and TGM on GL261 cells was investigated by MTT assay. The apoptotic effects of free Tan ⅡA, GL and TGM on GL261 cells were detected by flow cytometry.
      RESULTS  Thin film dispersion method was the best method to prepare self-assembled micelles loaded with tanshinone ⅡA glycyrrhizic acid. The particle size of TGM was about (121.87±5.85) nm, and the encapsulation efficiency of Tan ⅡA was (88.54±14.27)%, which was almost spherical in shape and the preparation was uniform and stable. TGM was capable of effective BBB-penetrating and the mechanism of uptake of self-assembled micelles by glioma cells was the uptake of preparations by clathrin-mediated endocytosis. TGM enhanced GL261 cell apoptosis from 12.28% (Free Tan ⅡA) and 13.32% (Free GL) to 31.16% (TGM), providing a promising potential to the GBM treatment.
      CONCLUSION  The TGM nano-micelles are self-assembled from GL and Tan IIA, which effectively overcomes low bioavailability and poor water solubility of Tan IIA. TGM can effectively cross the blood-brain barrier and be taken up by glioma cells through clathrin-mediated endocytosis, with good cytotoxicity and pro-apoptotic ability.
  • [1]
    李时珍. 本草纲目[M]. 北京: 中国书店, 1988: 21.

    LI SZ. Compendium of Materia Medica[M]. Beijing: China Bookstore, 1988: 21.
    [2]
    GAO S, LIU Z, LI H, et al. Cardiovascular actions and therapeutic potential of tanshinone ⅡA[J]. Atherosclerosis, 2012, 221(2): 604. DOI: 10.1016/j.atherosclerosis.2012.01.014
    [3]
    XIE J, LIU JH, LIU H, et al. The antitumor effect of tanshinone ⅡA on anti-proliferation and decreasing VEGF/VEGFR2 expression on the human non-small cell lung cancer A549 cell line[J]. Acta Pharm Sin B, 2015, 5(6): 554-563. DOI: 10.1016/j.apsb.2015.07.008
    [4]
    DONG WL, ZHANG YK, CHEN XM, et al. High-dose tanshinone ⅡA suppresses migration and proliferation while promoting apoptosis of astrocytoma cells via Notch-1 pathway[J]. Neurochem Res, 2018, 43(9): 1855-1861. DOI: 10.1007/s11064-018-2601-0
    [5]
    WANG J, WANG XJ, JIANG S, et al. Growth inhibition and induction of apoptosis and differentiation of tanshinone ⅡA in human glioma cells[J]. J Neuro Oncol, 2007, 82(1): 11-21. DOI: 10.1007/s11060-006-9242-x
    [6]
    KIM WS, KIM DO, YOON SJ, et al. Cryptotanshinone and tanshinone ⅡA enhance IL-15-induced natural killer cell differentiation[J]. Biochem Biophys Res Commun, 2012, 425(2): 340-347. DOI: 10.1016/j.bbrc.2012.07.093
    [7]
    ZHAO Q, LUAN X, ZHENG M, et al. Synergistic mechanisms of constituents in herbal extracts during intestinal absorption: Focus on natural occurring nanoparticles[J]. Pharmaceutics, 2020, 12(2): 128. DOI: 10.3390/pharmaceutics12020128
    [8]
    SELYUTINA OY, POLYAKOV NE. Glycyrrhizic acid as a multifunctional drug carrier-From physicochemical properties to biomedical applications: A modern insight on the ancient drug[J]. Int J Pharm, 2019, 559: 271-279. DOI: 10.1016/j.ijpharm.2019.01.047
    [9]
    LI S, ZHU JH, CAO LP, et al. Growth inhibitory in vitro effects of glycyrrhizic acid in U251 glioblastoma cell line[J]. Neurol Sci, 2014, 35(7): 1115-1120. DOI: 10.1007/s10072-014-1661-4
    [10]
    JUIN SK, GHOSH S, MAJUMDAR S. Glycyrrhizic acid facilitates anti-tumor immunity by attenuating Tregs and MDSCs: An immunotherapeutic approach[J]. Int Immunopharmacol, 2020, 88: 106932. DOI: 10.1016/j.intimp.2020.106932
    [11]
    WU WY, YAN H, WANG XB, et al. Sodium tanshinone ⅡA silate inhibits high glucose-induced vascular smooth muscle cell proliferation and migration through activation of AMP-activated protein kinase[J]. PLoS ONE, 2014, 9(4): e94957. DOI: 10.1371/journal.pone.0094957
    [12]
    ZHANG Y, WEI RX, ZHU XB, et al. Tanshinone ⅡA induces apoptosis and inhibits the proliferation, migration, and invasion of the osteosarcoma MG-63 cell line in vitro[J]. Anti Cancer Drugs, 2012, 23(2): 212-219. DOI: 10.1097/CAD.0b013e32834e5592
    [13]
    YUN SM, JUNG JH, JEONG SJ, et al. Tanshinone ⅡA induces autophagic cell death via activation of AMPK and ERK and inhibition of mTOR and p70 S6K in KBM-5 leukemia cells[J]. Phytother Res, 2014, 28(3): 458-464. DOI: 10.1002/ptr.5015
    [14]
    ZHANG KJ, LI J, MENG WT, et al. C/EBPβ and CHOP participate in Tanshinone ⅡA-induced differentiation and apoptosis of acute promyelocytic leukemia cells in vitro[J]. Int J Hematol, 2010, 92(4): 571-578. DOI: 10.1007/s12185-010-0686-6
    [15]
    CAI Y, ZHANG W, CHEN Z, et al. Recent insights into the biological activities and drug delivery systems of tanshinones[J]. Int J Nanomedicine, 2016, 11: 121-30. DOI: 10.2217/nnm.15.185
    [16]
    FAN LC, TENG HW, SHIAU CW, et al. SHP-1 is a target of regorafenib in colorectal cancer[J]. Oncotarget, 2014, 5(15): 6243-6251. DOI: 10.18632/oncotarget.2191
    [17]
    MA H, FAN Q, YU J, et al. Novel microemulsion of tanshinone ⅡA, isolated from Salvia miltiorrhiza bunge, exerts anticancer activity through inducing apoptosis in hepatoma cells[J]. Am J Chin Med, 2013, 41(1): 197-210. DOI: 10.1142/S0192415X13500146
    [18]
    LIU X, AN CY, JIN P, et al. Protective effects of cationic bovine serum albumin-conjugated PEGylated tanshinone ⅡA nanoparticles on cerebral ischemia[J]. Biomaterials, 2013, 34(3): 817-830. DOI: 10.1016/j.biomaterials.2012.10.017
    [19]
    ZHOU J, YU CH, PENG C. Anticancer effect of tanshinones on female breast cancer and gynecological cancer[J]. Front Pharmacol, 2022, 12: 824531. DOI: 10.3389/fphar.2021.824531
    [20]
    SUN J, XU ZS, HOU Y, et al. Hierarchically structured microcapsules for oral delivery of emodin and tanshinone ⅡA to treat renal fibrosis[J]. Int J Pharm, 2022, 616: 121490. DOI: 10.1016/j.ijpharm.2022.121490
    [21]
    ASHOUR AA, RAMADAN AA, ABDELMONSIF DA, et al. Enhanced oral bioavailability of Tanshinone ⅡA using lipid nanocapsules: Formulation, in-vitro appraisal and pharmacokinetics[J]. Int J Pharm, 2020, 586: 119598. DOI: 10.1016/j.ijpharm.2020.119598
